Day 1: How a Computer Works: From Transistors to Programs
After this lesson you will be able to explain, layer by layer, how billions of on/off switches become running programs — and use that mental model to reason about AI hardware, memory limits, and cost.
Hands-on lab for this lesson
Lab files on GitHub: https://github.com/ai-roadmap-365/ai-roadmap-365.github.io/tree/main/labs/sections/computing-foundations/day-001-how-a-computer-works-from-transistors
- Get the hands-on files. Clone the labs repository once (you can reuse this clone for every lesson). This works on macOS, Linux, and Windows (PowerShell or WSL):
git clone https://github.com/ai-roadmap-365/ai-roadmap-365.github.io.git cd ai-roadmap-365.github.io - Open this lesson's lab. Move into the directory for this specific day. Every lab lives at the same predictable path — section / subsection / week / day:
cd labs/sections/computing-foundations/day-001-how-a-computer-works-from-transistors - Read the lab guide. Open `README.md` in that directory. It lists the exact commands, what each does, the expected output, and how to check your work — read it before running anything.
- Run it and check your work. Follow the README's "How to run" section: run the example first to see the finished result, then complete the numbered exercises in `starter/`, then run the tests. The tests pass (exit 0) only when your work is correct.
bash tests/run_tests.sh # or the test command named in the lab README
You can also open the lab as a local page (works offline, shows the file tree and expected output).
Learning objectives
By the end of this lesson you will be able to:
- Explain how transistors combine into logic gates, and logic gates into circuits that add and remember, without appealing to any "magic" layer
- Describe the von Neumann architecture and why the stored-program idea makes one machine general-purpose
- Trace the fetch-decode-execute cycle step by step for a concrete ADD instruction, including the role of the program counter
- Rank the levels of the memory hierarchy by approximate latency and state the speed/size/cost trade-off that creates it
- Measure your own machine's CPU model, core count, RAM, disk space, and OS version from the terminal and place each in the layered stack
- Connect the memory hierarchy to AI practice: explain why model weights must fit in GPU memory and why quantization reduces memory footprint
Prerequisites
- A computer running macOS, Linux, or Windows with permission to open a terminal
- No prior programming or hardware knowledge — this is Day 1
Why this matters
Everything you build in this course runs on the machine described here, and the parts you meet today decide what is possible later.
-
A model is arithmetic on numbers held in memory. Nothing more exotic.
-
When training is slow, the cause is the processor, the memory, or the storage. Knowing which is the difference between a fix and a guess.
-
Nothing here is metaphor. Every claim in this lesson is something you can measure on your own machine, and the lab does.
The lesson has one destination: understanding why AI runs on GPUs, and why that is a fact about hardware rather than a fashion in software.
The idea in plain language
A computer is a machine that does one tiny thing, extremely fast, and is built in layers so that tiny thing adds up to everything else.
-
The tiny thing is a switch. On or off. One bit.
-
Each rung is built only from the rung below it. Nothing is added from outside — gates are switches, adders are gates, a processor is adders and registers with a clock.
-
The jump that matters is the last one. Instructions live in memory as data, so loading different instructions changes what the machine does. That is why one machine can do any job.
Historical background
The ideas arrived long before the hardware could carry them.
| When | What changed | Why it mattered |
|---|---|---|
| 1936 | Turing’s universal machine | One machine, reprogrammed, computes anything computable |
| 1945 | Von Neumann’s stored-program design | Instructions live in the same memory as data |
| Dec 1947 | The transistor | The switch becomes small, cheap and reliable |
| 1958 | The integrated circuit | Many switches on one piece of silicon |
| 1965 | Moore’s observation | Transistor counts double roughly every two years |
| 2007– | GPUs turned to general computing | Thousands of simple cores — the shape of a network |
- The 1945 design is the one in front of you, shrunk and repeated.
- Moore’s law was an observation, and it has slowed — which is exactly why parallel hardware became the way forward.
What it is — and what it is not
It is a stack of layers, each built only from the one below.
- Transistors form logic gates.
- Gates form the processor and memory.
- The processor executes machine code — raw binary instructions.
- The operating system is itself machine code, sharing the hardware out.
- Applications, including the models you will train, sit at the top.
It is not magic at any layer, and three misconceptions are worth naming:
- A computer does not “understand” anything. It moves and combines bits.
- Memory is not storage. RAM empties at power-off; the disk does not.
- The processor does not do many things at once. It takes very fast turns, which Day 7 measures.
Why it was created and what problems it solves
Every layer exists because the one below it was too hard to use directly.
-
Rewiring was the original problem. Early machines were reconfigured physically for each job; the stored-program design replaced hours of cabling with loading a different file.
-
Vacuum tubes were unreliable and enormous. The transistor made switches small, cool and durable enough to use by the billion.
-
Machine code is unusable at scale. Languages, and then operating systems, exist so a person can express intent without naming registers.
The pattern repeats all the way up: each layer hides the one beneath it well enough that you can forget it — until performance makes you remember.
How it works
From switch to arithmetic
Arithmetic and memory are not abilities the machine has. They are shapes that gates are arranged into.
The parts, and what each is for
| Component | What it does | Everyday analogue |
|---|---|---|
| CPU | Executes instructions one after another, very fast | The chef cooking |
| RAM | Fast temporary workspace; empties at power-off | The counter and pantry |
| Storage | Slow but permanent home for files and the OS | The warehouse across town |
| GPU | Thousands of simple cores doing the same arithmetic at once | A hall of cooks chopping |
| Bus | The wiring connecting them | The corridors |
One instruction, four stages
Registers R1 and R2 hold 5 and 3. The instruction is ADD R1, R2 -> R3.
- Fetch — the program counter names an address; memory returns the bits.
- Decode — the control unit routes R1 and R2 into the ALU.
- Execute — binary 0101 and 0011 go in, 1000 comes out. Pure physics.
- Write back — the result lands in R3; status flags update.
About three billion times a second. That is all a CPU ever does.
Because the program counter is just a register, an instruction can change it. Jumping backward is a loop; jumping conditionally is a decision. Loops plus decisions plus arithmetic is everything software is made of.
Why memory is a pyramid
Fast memory needs more transistors per bit and must sit close to the ALU, so machines layer a little of it over larger, slower, cheaper tiers.
- Registers — about one cycle, a fraction of a nanosecond
- Cache — one to a few tens of nanoseconds
- RAM — about 100 nanoseconds
- SSD — about 100 microseconds, a thousand times slower than RAM
- Register to SSD is roughly a factor of a million. At one second per register access, the SSD trip takes about a week.
It works because programs reuse recent data and march through it in order — locality — so hardware keeps hot data in the fast tiers by itself.
An everyday analogy
A restaurant kitchen, where every part maps onto something real.
| Kitchen | Machine |
|---|---|
| The chef’s hands | The ALU — where work actually happens |
| The cutting board | Registers — a few items, instantly reachable |
| The counter and pantry | RAM — today’s ingredients |
| The warehouse across town | Storage — everything, but a trip away |
| The recipe card | The program, held in memory as data |
| A hall of prep cooks | The GPU — many hands, one repeated task |
-
The chef is fast; the trip to the warehouse is not. That single asymmetry is the memory hierarchy.
-
Swap the recipe card and the kitchen makes something else. That is the stored-program idea.
Examples in practice
Where this becomes AI:
-
A 7-billion-parameter model at 16 bits is about 14 GB of weights.
-
Each token read costs one full pass over all of them.
-
So a 400 GB/s bus caps output near 30 tokens per second, however fast the arithmetic units are.
-
At 4 bits instead of 16 the model is 3.5 GB and the ceiling roughly quadruples.
Day 3 measures this properly. Today it is enough to see that it is the pyramid.
Implications: security, privacy, performance, scalability, and cost
-
Performance. Most slow programs are waiting for data, not computing. Look at the hierarchy before optimising arithmetic.
-
Scalability. More cores help only work that can be split.
-
Cost. Each step down the pyramid is roughly an order of magnitude cheaper per byte — which is why the pyramid exists.
-
Security. Isolation is enforced by hardware, not good manners.
-
Privacy. Deleting a file usually removes the pointer, not the bytes.
-
Energy. Moving data costs far more than computing on it.
Alternatives: free, open source, and commercial
| Resource | Type | What it gives you |
|---|---|---|
| The Day 1 lab | Free | Your own machine’s real numbers |
| Crash Course Computer Science | Free video series | Short visual episodes from transistors upward |
| Nand2Tetris | Free course | Build a working computer from NAND gates |
| Ben Eater’s breadboard CPU | Free video series | A processor built by hand, one wire at a time |
| Petzold, Code | Book | The clearest prose account of the whole ladder |
| Patterson & Hennessy | Textbook | The standard university treatment |
-
Nand2Tetris is the one to do if today’s abstraction ladder felt like a claim rather than a fact — you build every rung yourself.
-
Everything above is free except the books, and the free options are not the lesser ones.
Comparison with related concepts
| Often confused | The actual difference |
|---|---|
| CPU vs GPU | Few clever cores vs thousands of simple ones doing the same thing |
| Core vs thread | A physical unit vs a stream of instructions it can interleave |
| Memory vs storage | Volatile and fast vs permanent and slow |
| Machine code vs source | What the CPU executes vs what a person writes |
When to use it — and when not to
Reach for this model when something is slower than it should be, a program will not fit in memory, you are choosing hardware, or you need to explain why a model runs on one machine and not another.
Do not reach for it when you are writing ordinary application code. The layers exist so you can ignore them, and reasoning about cache lines while writing a data-loading script is a way to write it badly and slowly.
The rule: work at the highest layer that solves your problem, and go down one level only when a measurement tells you to.
The AI connection
-
A model is arithmetic on numbers held in memory, executed by a processor, loaded from storage. When a training run is slow, it is one of those three.
-
A neural network is almost entirely matrix multiplication — the same multiply-accumulate repeated across millions of values.
-
That is exactly the shape a GPU was built for, which is why the field moved onto graphics hardware. A hardware fact, not a software preference.
-
Everything later is downstream of this. Batch sizes, memory limits and inference cost all trace back to the switching elements you met today.
Knowledge check
Try these from memory before looking back:
- Name the layers of the computing stack in order from physics to applications, with one sentence on what each provides to the layer above.
- A friend says their computer “understands” them because it autocorrects typos. Explain what is really happening and why “understanding” is the wrong word for the hardware.
- Without looking at the diagram, describe the four steps of executing
ADD R1, R2 -> R3, including the program counter’s role. - Your laptop crawls whenever you open a very large dataset, yet the CPU meter shows low usage. Using the memory hierarchy, give the most likely explanation.
- In three sentences or fewer, explain to a non-technical person why AI companies buy GPUs instead of simply faster CPUs.
Hands-on exercise
Ask your own machine what hardware it has, then place each answer in the layers diagram. Full instructions are in the Day 1 lab directory.
| What you want | macOS | Linux |
|---|---|---|
| CPU model | sysctl -n machdep.cpu.brand_string | lscpu |
| RAM in bytes | sysctl hw.memsize | free -h |
| Logical cores | sysctl -n hw.ncpu | nproc |
| Disk size and free | df -h / | df -h / |
| OS version | sw_vers | cat /etc/os-release |
On Windows, use Get-ComputerInfo in PowerShell — or install WSL, since later
lessons assume a Unix-style terminal.
Expected output
$ sysctl -n machdep.cpu.brand_string
Apple M2
$ sysctl hw.memsize
hw.memsize: 17179869184
$ sysctl -n hw.ncpu
8
$ df -h /
/dev/disk3s1s1 460Gi 9.8Gi 180Gi 6% /
- 17179869184 bytes ÷ 1073741824 = 16 GiB of RAM.
- 8 logical cores — streams that can run at once, not necessarily 8 chips.
- 460 GiB disk — the figures need not sum, because macOS splits the disk across system volumes.
Validate your work
You are done when you can state, from your own machine:
- The CPU model and its logical core count
- RAM in GB, converted from bytes
- Roughly how much free disk space you have
- The OS name and version
- Where each of those sits in the layers diagram
Troubleshooting
-
command not found— you used the other operating system’s command.sysctlis macOS;lscpu,freeandnprocare Linux. -
Permission errors — none of these need
sudo. The cause is almost always a typo; retype exactly, including spaces. -
A giant number instead of gigabytes —
hw.memsizereports bytes. Divide by 1073741824. -
dfshows several rows — read the one mounted on/.
Common mistakes
-
Confusing RAM with disk. “512 GB” on a laptop box is storage. RAM is usually 8–32 GB. Mixing them up means buying the wrong upgrade.
-
Confusing cores with threads. Many CPUs run two streams per physical core, so “8 CPUs” may be a 4-core chip.
-
Reading “memory used” as “memory needed.” The OS keeps RAM full on purpose, using the spare as disk cache. Pressure shows up as swap, not as “used”.
Practice assignment
Find the real numbers for the machine in front of you.
-
Record the specification. Processor model, core count, RAM, storage type and size, and whether there is a discrete GPU.
-
Place them on the pyramid. Attach an approximate latency to each tier from the lesson, and note which ones your machine actually has.
-
Answer one question in two sentences. What is the largest model, at 2 bytes per weight, that could theoretically sit in your RAM — and what would you expect to happen if you tried to run one twice that size?
Extension challenge
Go one level deeper into the hierarchy you have just placed your machine on.
-
Find your cache sizes.
sysctl -a | grep cachesizeon macOS,lscpuon Linux. Record L1, L2 and L3. -
Compare the tiers. Write the ratio of L1 to L3, and of L3 to your RAM.
-
Predict, then check. Which is the bigger jump in size, and which in latency? They are not the same tier, and the reason is the whole point of the pyramid.
Quiz
Q1. What is the fundamental role of a transistor in a computer?
- It stores a complete file permanently
- It cools the processor while it runs
- It converts binary numbers into decimal numbers
- It acts as a switch that is either on or off
Show answer
Answer: D. It acts as a switch that is either on or off
A transistor is a microscopic switch whose on/off state represents one bit of possibility; billions of them wired into logic gates form all of a computer's processing and memory circuitry.
Q2. Which sequence correctly orders the steps a CPU repeats for every instruction?
- Fetch, decode, execute, write back
- Execute, decode, fetch, write back
- Decode, fetch, execute, write back
- Fetch, execute, decode, write back
Show answer
Answer: A. Fetch, decode, execute, write back
The CPU first fetches the instruction from memory, then the control unit decodes its bit pattern, the ALU executes the operation, and the result is written back to a register or memory before the cycle repeats.
Q3. What is the key difference between RAM and storage (SSD/disk)?
- RAM holds programs while storage holds only pictures and documents
- RAM is fast but empties at power-off; storage is slower but permanent
- RAM is measured in terabytes while storage is measured in gigabytes
- Storage is faster than RAM but more expensive per byte
Show answer
Answer: B. RAM is fast but empties at power-off; storage is slower but permanent
RAM is the machine's fast, volatile workspace for running programs, while storage is the slower, persistent layer that survives shutdown — roughly a thousand times slower than RAM for an SSD.
Q4. The capital letter A is stored in a computer using ASCII as which of the following?
- The binary pattern 00000001, which is the number 1
- A miniature photograph of the letter shape
- The binary pattern 01000001, which is the number 65
- A special letter-transistor distinct from number-transistors
Show answer
Answer: C. The binary pattern 01000001, which is the number 65
ASCII assigns the number 65 to capital A, and 65 in binary is 01000001; text, like everything else in a computer, is bit patterns given meaning by convention.
Q5. What was the central insight of the von Neumann architecture described in the 1945 EDVAC report?
- Computers should use decimal arithmetic instead of binary
- Every computer needs a separate machine for each task it performs
- Processors should be built from vacuum tubes rather than relays
- Programs live in the same memory as data, making one machine general-purpose
Show answer
Answer: D. Programs live in the same memory as data, making one machine general-purpose
Storing instructions in memory alongside data means a computer can switch tasks just by loading different instructions, instead of being physically rewired like ENIAC.
Q6. Why do computers use a memory hierarchy instead of building all memory as fast as registers?
- Fast memory costs more per byte and must sit close to the CPU
- Slow memory produces more accurate results than fast memory
- Operating systems cannot address more than a few kilobytes of fast memory
- Registers wear out quickly, so they are kept scarce as spare parts
Show answer
Answer: A. Fast memory costs more per byte and must sit close to the CPU
Speed, size, and cost trade off against each other: register-speed memory is expensive and must sit near the ALU, so machines pair tiny fast layers with progressively larger, slower, cheaper ones and rely on locality to make it work.
Q7. Why are GPUs better suited than CPUs for running neural networks?
- GPUs have higher clock speeds than any CPU
- Thousands of simple cores do the same math on many values at once
- GPUs store model weights permanently even when powered off
- GPUs understand the meaning of the data they process
Show answer
Answer: B. Thousands of simple cores do the same math on many values at once
Neural networks consist mostly of huge uniform grids of multiplications and additions, which map naturally onto a GPU's thousands of parallel arithmetic cores rather than a CPU's few powerful sequential cores.
Q8. What does it mean to say a computer is a "stored-program" machine?
- Its programs are permanently burned into the processor at the factory
- It keeps a backup of every program it has ever run
- Its instructions live in memory as data, so loading new ones changes its job
- Programs can only be loaded from external punched cards
Show answer
Answer: C. Its instructions live in memory as data, so loading new ones changes its job
Because the program lives in memory just like data, the same hardware can become a calculator, a text editor, or a neural network simply by loading different instructions — the foundation of general-purpose computing.
Glossary
- transistor
- A microscopic electrical switch with no moving parts whose on/off state is the physical basis of all digital computing.
- logic gate
- A small circuit built from transistors that computes a simple rule, such as AND (output on only if both inputs are on), OR, or NOT.
- binary
- A way of writing numbers and encoding all data using only two digits, 0 and 1, which map directly onto a switch's off and on states.
- bit
- The smallest unit of information, a single 0 or 1.
- byte
- A group of 8 bits, enough to store one of 256 possible values, such as a single ASCII character.
- CPU
- The central processing unit, the chip that executes program instructions one after another by repeating the fetch-decode-execute cycle.
- register
- One of a small set of ultra-fast storage slots inside the CPU that hold the values being worked on at this instant.
- RAM
- Random-access memory, the computer's fast temporary workspace that holds running programs and their data and is emptied when power is cut.
- cache
- Small, very fast memory on the CPU chip that keeps recently used data close to the processor so it rarely has to wait on slower RAM.
- machine code
- The raw binary instructions a CPU executes directly, the lowest-level form of any program.
- operating system
- The master program that manages the hardware, shares the CPU and memory among running programs, and handles all input and output.
- memory hierarchy
- The layered arrangement of storage from registers through cache and RAM to disk, trading speed against size and cost per byte at each level.
Sources and further reading
- Code: The Hidden Language of Computer Hardware and Software (2nd ed.) — Charles Petzold / Microsoft Press (accessed 2026-07-12) — The classic book-length treatment of this lesson’s layered story.
- Crash Course Computer Science — PBS Digital Studios (accessed 2026-07-12) — Free 40-episode video series covering transistors through operating systems.
- Von Neumann architecture — Wikipedia (accessed 2026-07-12)
- From Nand to Tetris — Shimon Schocken and Noam Nisan (accessed 2026-07-12) — Free course where you build a computer from logic gates up.
- CS50: Introduction to Computer Science — Harvard University (accessed 2026-07-12)
Kept in this browser, no account needed. Your progress page turns the whole record into one link you can bookmark or open on another device.
