Day 39: Data Storage: Files, Databases, Object Storage, and Caches
After this lesson you will be able to name the four main ways software stores data — files, databases, object storage, and caches — explain the trade-offs that separate them, and choose the right store for a given workload on purpose instead of by habit.
Hands-on lab for this lesson
Lab files on GitHub: https://github.com/ai-roadmap-365/ai-roadmap-365.github.io/tree/main/labs/sections/computing-foundations/day-039-data-storage-files-databases-object-storage
- Get the hands-on files. Clone the labs repository once (you can reuse this clone for every lesson). This works on macOS, Linux, and Windows (PowerShell or WSL):
git clone https://github.com/ai-roadmap-365/ai-roadmap-365.github.io.git cd ai-roadmap-365.github.io - Open this lesson's lab. Move into the directory for this specific day. Every lab lives at the same predictable path — section / subsection / week / day:
cd labs/sections/computing-foundations/day-039-data-storage-files-databases-object-storage - Read the lab guide. Open `README.md` in that directory. It lists the exact commands, what each does, the expected output, and how to check your work — read it before running anything.
- Run it and check your work. Follow the README's "How to run" section: run the example first to see the finished result, then complete the numbered exercises in `starter/`, then run the tests. The tests pass (exit 0) only when your work is correct.
bash tests/run_tests.sh # or the test command named in the lab README
You can also open the lab as a local page (works offline, shows the file tree and expected output).
Learning objectives
By the end of this lesson you will be able to:
- Describe the four main storage shapes — file, database, object storage, cache — and give a concrete best-fit workload for each
- Explain why relational databases exist: schemas, ACID transactions, and indexes, and how they make concurrent updates safe and queries fast
- Distinguish the four NoSQL families (key-value, document, wide-column, graph) and when each fits better than a relational database
- Contrast object storage with block and file storage, and explain the bucket-and-key model for huge, cheap, immutable blobs
- Explain how a cache sits in front of a slow store, why it is volatile, and what cache invalidation and a TTL are, tying it back to the memory hierarchy
- Apply a decision process to pick a store for a real workload, weighing durability, consistency, speed, and cost
- Connect storage choices to AI systems: datasets and model weights in object storage, vector databases for embeddings, and caching to cut cost
Prerequisites
- Day 3 (the memory hierarchy: registers, cache, RAM, storage) and Day 5 (data as bytes)
- A terminal with bash and sqlite3 (preinstalled on macOS and most Linux)
- No prior database experience required
Why this matters
-
Every AI system stores four kinds of thing — datasets, model weights, metadata and predictions — and they want different stores.
-
Choosing wrongly is expensive to undo. Data outlives the code that wrote it.
-
A dataset in a database and a database in a bucket are both common mistakes, and both are slow in ways that look like something else.
-
Caching is the Day 3 memory hierarchy moved up a level, and it is the cheapest performance win available.
-
Cost differences here are orders of magnitude, not percentages.
The idea in plain language
-
Four shapes cover almost everything: files, relational databases, object storage and caches.
-
The right one follows from your access pattern, not from the size of the data.
-
A file is the simplest thing that works, and simplicity is a feature.
-
A database earns its complexity when you need precise queries or many concurrent writers.
-
Object storage is for large blobs; a cache is for the hot subset of anything else.
Historical background
-
Files came first, and the hierarchical filesystem of the 1960s is essentially what you use today.
-
The relational model was proposed by Edgar Codd in 1970, and its insight was to separate what you want from how to fetch it — which is what SQL expresses.
-
That separation is why databases could get faster for decades without anyone rewriting their queries.
-
NoSQL emerged in the 2000s when web-scale workloads outgrew what one relational machine could do, trading guarantees for scale.
-
Object storage arrived with cloud computing, discarding the folder tree entirely in exchange for effectively unlimited, cheap, durable capacity.
-
The pendulum has swung back somewhat. Relational databases now handle scales that once justified abandoning them, and “start relational” is sound advice again.
What it is — and what it is not
These are:
- Four different shapes for holding data, with different access patterns.
- Complementary. A real system uses several at once.
- Chosen by how the data is read and written, more than by how much of it there is.
They are not:
-
Not a hierarchy. Object storage is not “better files”; it is a different shape with different trade-offs.
-
Not interchangeable. A bucket cannot answer a query; a database is a poor place for a 5 GB file.
-
Not permanent decisions in principle, but usually in practice. Migrating data is far harder than changing code.
-
Not about size alone. A tiny dataset with thousands of concurrent writers needs a database; a huge one read whole needs a bucket.
Why it was created and what problems it solves
-
Concurrent writers. A file breaks down the moment several processes write it at once; a database exists to make that safe.
-
Precise queries. “The total per customer in Ohio” is a database question, and answering it by reading a whole file does not scale.
-
Durability at scale. Object storage keeps multiple copies across machines, which a single disk cannot.
-
Cost. Storing terabytes in a database costs far more than storing them in a bucket, for no benefit if you only read them whole.
-
Speed. A cache exists because the same small subset of data is requested repeatedly, and RAM is far faster than anything else.
How it works
Files and filesystems
-
A filesystem organises a disk into named files in a tree, tracking where each file’s bytes physically live.
-
Unstructured files are opaque blobs — a JPEG, an MP4, a compiled program — whose bytes mean something only to the program that reads them.
-
Structured files impose a parseable format: CSV, JSON, YAML.
-
A file is often enough. For configuration, a small dataset, a log — anything read far more than written, by one program at a time.
-
You reach past files when you hit their limits: many concurrent writers, or queries more precise than “read the whole thing”.
Relational databases
- Data lives in tables with fixed, typed columns; each row is one record.
- A schema is the declared structure — which tables, which columns, which rules hold.
SELECT customer, SUM(amount) AS total
FROM orders
WHERE state = 'OH'
GROUP BY customer;
- Behind that one statement, the database uses indexes to find matching rows fast, runs the aggregate, and wraps writes in a transaction so a crash mid-update never leaves a half-written mess.
Three storage shapes, often confused
-
Block storage is a raw disk carved into fixed-size blocks — what your SSD presents, what a cloud volume gives a virtual machine. It is the fast foundation everything else is built on.
-
File storage is a filesystem: blocks organised into the named-files-in-folders tree, shareable over a network.
-
Object storage is neither: a flat pool of whole objects addressed by key.
NoSQL families
-
A key-value store is a giant dictionary — hand it a key, get a value, extremely fast. Sessions, caches, simple lookups.
-
A document store keeps self-contained JSON-like documents with no fixed schema, which suits records whose shape varies.
-
A wide-column store spreads enormous tables across many machines, tuned for massive write volumes.
-
A graph database stores nodes and edges, making “friends of friends” and “shortest path” natural — questions that tie a relational database in knots.
Object storage
-
You create a bucket, and store each object under a key, a string name.
-
An object is an immutable blob plus a little metadata. You
PUTit and laterGETit by key. -
Keys often look like paths —
datasets/2026/train.csv— but that is a naming convention. The namespace is flat; there are no real folders. -
Objects are cheap, highly durable and effectively unlimited, which is why buckets are the natural home for datasets, media, backups and large model files.
-
The trade-off: you replace objects wholesale rather than editing in place, and you cannot run SQL over their contents.
Caches
-
A cache sits in front of a slower store, holding the hottest data in RAM so most reads never reach the slow store.
-
The pattern: check the cache; on a hit, return immediately; on a miss, fetch from the real store, put a copy in the cache, and return it.
-
This is Day 3’s memory hierarchy — fast-and-small in front of slow-and-large — moved up a level.
-
The hard part is invalidation. When the underlying data changes, stale copies must be updated or evicted, or users see old data.
-
A time-to-live is the common tactic: each entry expires after a set number of seconds, trading a little staleness for a great deal of simplicity.
An everyday analogy
Storing things in a building.
| The building | The store |
|---|---|
| A labelled box on a shelf | A file |
| A filing system with an index and rules | A relational database |
| A vast warehouse, everything by ticket number | Object storage |
| The tray on your desk | A cache |
| The floor and the shelving | Block storage |
-
A box is fine until several people need to write in it at once.
-
The warehouse is cheap and enormous, and you cannot ask it “how many blue ones are there?” — only “fetch ticket 4,812”.
-
The tray holds what you keep reaching for. Its whole problem is remembering to update it when the real thing changes.
Examples in practice
-
A 200 GB dataset stored as rows in a database, when it is only ever read whole — slow, and expensive by an order of magnitude.
-
Model checkpoints in a bucket with the run’s commit hash in the key, which is how a result stays traceable.
-
A cache with no expiry serving three-day-old prices, which is invalidation failing exactly as predicted.
-
A CSV that worked perfectly until two processes appended to it simultaneously.
-
A graph query that ran for an hour in a relational database and in milliseconds in a graph one.
Implications: security, privacy, performance, scalability, and cost
-
Security: a public bucket is the most common cloud data breach there is. Default to private, and check.
-
Encrypt at rest and in transit, which is usually one setting each and is expected of anything holding personal data.
-
Privacy: data outlives the code. Deletion requirements apply to backups, caches and object versions, all of which are easy to forget.
-
Performance: the access pattern decides everything. Random small reads and sequential whole-file reads want opposite stores.
-
Scalability: caches fail in a specific way. If the cache empties and every request hits the real store at once, the store falls over — a stampede, and the same shape as Day 27’s thundering herd.
-
Cost: object storage is roughly an order of magnitude cheaper per terabyte than database storage, and egress usually costs more than storage does.
Alternatives: free, open source, and commercial
| Option | Type | Where it fits |
|---|---|---|
| SQLite | Free, open source | A whole relational database in one file. Start here far more often than people do. |
| PostgreSQL | Free, open source | The default relational choice; handles JSON and vectors too |
| Redis | Free, open source | Caching, sessions, queues |
| S3-compatible object storage | Commercial, free tiers | Datasets, media, checkpoints, backups |
| Parquet on object storage | Free format | Large analytical datasets, columnar and compressed |
| Vector databases | Free and commercial | Similarity search over embeddings |
-
SQLite is underrated. It is a real relational database in a single file, with no server, and it is the right answer for a great many projects that reach for PostgreSQL.
-
PostgreSQL now covers what NoSQL was once needed for — documents, and vectors — which makes “start relational” sound advice again.
Comparison with related concepts
| Term | What it actually is |
|---|---|
| Block storage | Raw fixed-size blocks; the foundation |
| File storage | Named files in a folder tree |
| Object storage | A flat pool of blobs addressed by key |
| Schema | The declared structure of a database |
| Transaction | A group of changes that all apply or none do |
| Index | A structure making lookups fast |
| TTL | How long a cached entry stays valid |
When to use it — and when not to
-
Start with a file. Move on when you can name the limit you have hit.
-
Use a relational database when you need queries, constraints or concurrent writers. Start with SQLite; move to PostgreSQL when you need a server.
-
Use object storage for anything large and read whole — datasets, media, checkpoints, backups.
-
Add a cache only after measuring, and always with an expiry.
-
Do not put large blobs in a database. It works, it is expensive, and it makes backups painful.
-
Do not put queryable data in object storage and then write code to scan every object. That code is a slow database.
-
Do not choose NoSQL for scale you do not have. You give up real guarantees for a problem you may never meet.
The AI connection
-
Training data belongs in object storage, as Parquet or JSONL — cheap, durable and read sequentially, which is exactly the access pattern.
-
Model weights belong in object storage too, versioned by key, never in Git.
-
Experiment metadata belongs in a relational database: which run, which config, which metric, which commit hash. Those are queries.
-
Embeddings need a vector store, whether a dedicated one or PostgreSQL with an extension, because similarity search is not a query a normal index can serve.
-
Caching model responses is the single biggest cost saving available for a deployed AI system, since identical prompts are far more common than people expect.
Knowledge check
quiz:
question: "A team stores a 200 GB training dataset as rows in a relational database. It is only ever read in full, sequentially, for training. What is the main problem?"
options:
- "They are paying database prices and overhead for an access pattern object storage serves better and far more cheaply"
- "Relational databases cannot store datasets larger than a few gigabytes"
- "Sequential reads are impossible in a relational database, so training will fail"
- "The data must be normalised into multiple tables before it can be queried"
answer_index: 0
explanation: "The database's indexes, transactions and query planning all exist to serve selective access, and none of them helps a full sequential scan. The workload wants cheap bulk storage read whole, which is precisely what object storage is for — at roughly a tenth of the cost."
Hands-on exercise
Store the same data four ways and measure the difference. Worked through fully in the Day 39 lab directory.
| What you are doing | Command |
|---|---|
| Query a file | python3 -c "import csv,sys; ..." over a CSV |
| Load it into SQLite | sqlite3 data.db ".import data.csv orders" |
| Query with SQL | sqlite3 data.db "SELECT customer, SUM(amount) ... GROUP BY customer" |
| Add an index and re-time | CREATE INDEX idx_state ON orders(state); |
| Store a blob by key | The lab’s local object-store stand-in |
| Cache a result | Store it in a dictionary with a timestamp, and expire it |
| Compare | Time all four for the same question |
Expected output
scan whole CSV: 1.84s
sqlite, no index: 0.42s
sqlite, with index: 0.008s
cache hit: 0.00002s
-
The index is the whole reason a database is faster, and it changed nothing about the query you wrote.
-
The cache is another two orders of magnitude, and it is only correct while the underlying data has not changed.
Validate your work
- You answered the same question against a file and a database and timed both
- You added an index and measured the difference
- You stored and retrieved a blob by key
- You implemented a cache with an expiry and demonstrated both a hit and a miss
- You can name the access pattern each of the four shapes suits
-
bash tests/run_tests.shreports 0 failures
Troubleshooting
-
The index made no difference. The query does not filter on that column, or the table is small enough to scan regardless.
-
SQLite refuses concurrent writes. That is the limit being demonstrated; it allows one writer at a time.
-
Your cache returns stale data. That is invalidation, and it is the hard part. Add an expiry.
-
The CSV parse is the slow part, not the query. Which is itself the finding.
Common mistakes
- Reaching for a database before hitting a file’s limits.
- Caching without an expiry.
- Storing large blobs as database rows.
- Assuming object-storage keys are folders. They are one flat string.
Practice assignment
-
Take one dataset and store it four ways, then write down which question each store answers best.
-
Find the size at which scanning a file becomes slower than a query, on your own machine, for your own data.
-
Implement a cache with a TTL and deliberately let it serve stale data, so you have seen the failure mode.
-
Cost out one terabyte in a managed database and in object storage, using current public prices. The ratio is the argument.
Extension challenge
-
Reproduce a cache stampede: empty the cache while many requests are in flight, and watch every one of them hit the slow store at once. Then fix it, and note that the fix is the same shape as Day 27’s.
-
Compare CSV against Parquet on a million rows: file size, full-scan time, and time to read one column.
-
Query object storage without downloading it — several services can run SQL over objects in place — and compare that with loading it into a database first.
-
Build a tiny vector search over a few thousand embeddings, first by brute force and then with an index, and measure where brute force stops being acceptable.
Quiz
Q1. Which storage shape is the right home for a plain configuration file that one program reads and that changes rarely?
- A relational database, for the ACID guarantees
- Object storage, because keys look like paths
- A file — the simplest thing that works for one reader
- A cache, because config is read often
Show answer
Answer: C. A file — the simplest thing that works for one reader
A file is the simplest correct choice when data is read far more than written and by one program at a time. You reach past files only when many concurrent writers or precise queries appear — none of which a rarely-changing config needs.
Q2. Two withdrawals hit a bank balance stored in a plain file at the same time; both read 100, subtract 30, and write 70, so one withdrawal is lost. Which property of relational databases prevents this?
- Indexes, because they sort the data
- Object immutability, because blobs cannot change
- A time-to-live, which expires stale data
- ACID transactions, making related changes all-or-nothing
Show answer
Answer: D. ACID transactions, making related changes all-or-nothing
ACID (Atomicity, Consistency, Isolation, Durability) wraps related changes in a transaction that fully happens or not at all and stops two clients from stepping on each other, so no update silently vanishes.
Q3. Why can a database answer "customers in Ohio" far faster than grepping a million-line file for the same thing?
- The database keeps an index, so it jumps instead of scanning
- The database stores the data in RAM and the file is always on disk
- grep is written in a slow programming language
- The database compresses the data so there is less to read
Show answer
Answer: A. The database keeps an index, so it jumps instead of scanning
An index is an extra sorted structure that lets the database find relevant rows directly, turning a full scan into a quick lookup. A plain file has no index, so answering the same question means reading and scanning everything.
Q4. In object storage, how is a stored object identified and retrieved?
- By its row number in a table
- By bucket and key, fetching the whole object back
- By opening a file handle and seeking to an offset
- By a SQL SELECT over the object contents
Show answer
Answer: B. By bucket and key, fetching the whole object back
Object storage puts each object in a bucket under a key and you GET the whole object back by that key. The namespace is flat — keys may look like paths but there are no real folders — and you cannot run SQL over the contents or edit an object in place.
Q5. Which statement about a cache is true?
- A cache is the durable source of truth for your data
- A cache must be a relational database
- A fast volatile copy in front of a slower store
- A cache permanently replaces the store behind it
Show answer
Answer: C. A fast volatile copy in front of a slower store
A cache holds copies of hot data in fast memory so most reads never touch the slow store. It is volatile and disposable — if you cannot afford to lose it, it is not a cache but a source of truth.
Q6. Which NoSQL family is the natural fit for "friends of friends" or shortest-path questions about connected entities?
- Key-value store
- Wide-column store
- Document store
- Graph database
Show answer
Answer: D. Graph database
A graph database stores nodes and the edges between them, making relationship traversals like "friends of friends" or shortest path natural — exactly the queries that tie a relational database in knots with repeated joins.
Q7. Where should a 5 GB training dataset live, and where should the record describing it (name, owner, date) live?
- The dataset in object storage; the record in the database
- Both in a cache, for speed
- Both in the relational database, in the same table
- The dataset in a relational database; the record in a plain file
Show answer
Answer: A. The dataset in object storage; the record in the database
Large blobs belong in cheap, durable object storage; the database stores only the key plus structured, queryable metadata. Putting the 5 GB blob in the database would bloat it, slow every backup, and cost far more.
Q8. What is "cache invalidation," and why is a time-to-live (TTL) a common way to handle it?
- It is deleting the underlying database; a TTL schedules that deletion
- Keeping stale copies fresh; a TTL expires each entry
- It is validating SQL syntax before a query runs
- It is encrypting cached data; a TTL sets the encryption key lifetime
Show answer
Answer: B. Keeping stale copies fresh; a TTL expires each entry
When the underlying data changes, cached copies can go stale, so they must be refreshed or evicted. A TTL expires each entry after a set number of seconds, trading a little possible staleness for simplicity instead of tracking every change precisely.
Glossary
- file
- A named blob of bytes stored on disk and organized by a filesystem into folders; the simplest storage shape, ideal when data is read far more than written and by one program at a time.
- filesystem
- The part of an operating system that organizes a disk into named files inside a tree of folders and tracks where each file's bytes physically live.
- database
- A running program whose whole job is to store data so it can be queried and changed safely, even when many clients access it at once.
- relational database
- A database that stores data in tables of rows and typed columns under a fixed schema, queried with SQL and protected by ACID transactions; examples include PostgreSQL, MySQL, and SQLite.
- SQL
- Structured Query Language, the standard language for asking questions of and changing data in a relational database, with clauses such as SELECT, WHERE, and GROUP BY.
- schema
- The declared structure of a relational database: which tables exist, which typed columns each has, and which rules (uniqueness, references) must hold.
- NoSQL
- A family of non-relational databases — key-value, document, wide-column, and graph — that trade some of the relational model's strict rules for scale, flexibility, or specialized query shapes.
- ACID
- The four guarantees a relational transaction provides — Atomicity (all-or-nothing), Consistency (no invalid state), Isolation (concurrent clients do not corrupt each other), and Durability (committed data survives a crash).
- index
- An extra sorted lookup structure a database maintains so it can jump straight to matching rows instead of scanning every row, turning a slow full scan into a fast lookup.
- object storage
- A flat store of large, immutable blobs addressed by a key inside a bucket; cheap, highly durable, and effectively unlimited, and the natural home for datasets, media, backups, and model files.
- bucket
- The top-level container in object storage that holds objects, each stored under a key; the S3-style equivalent of a namespace for your blobs.
- key-value store
- A NoSQL database that works like a giant dictionary — hand it a key, get a value back very fast — ideal for sessions, caches, and simple lookups; Redis and DynamoDB are examples.
- cache
- A fast, volatile copy of frequently used data placed in front of a slower store so most reads never reach the slow store; disposable, because the durable data lives elsewhere.
- cache invalidation
- The problem of keeping cached copies from going stale when the underlying data changes, often handled with a time-to-live (TTL) that expires each entry after a set time.
- durability
- The guarantee that once data is committed to a store it survives crashes and restarts; object storage and databases provide it, while a cache deliberately does not.
Sources and further reading
- Appropriate Uses For SQLite — SQLite (accessed 2026-07-12) — The SQLite project's own guidance on when an embedded database is the right choice, including as a replacement for ad-hoc files.
- Database — Wikipedia (accessed 2026-07-12)
- Object storage — Wikipedia (accessed 2026-07-12)
- Cache (computing) — Wikipedia (accessed 2026-07-12)
- Computer data storage — Wikipedia (accessed 2026-07-12)
Kept in this browser, no account needed. Your progress page turns the whole record into one link you can bookmark or open on another device.
