Day 19: HTTPS and TLS: Encryption on the Wire
After this lesson you will be able to explain how HTTPS secures a web connection — the handshake, the mix of symmetric and public-key encryption, and the certificate chain of trust — and use openssl and curl to inspect any site's certificate and diagnose common TLS errors.
Hands-on lab for this lesson
Lab files on GitHub: https://github.com/ai-roadmap-365/ai-roadmap-365.github.io/tree/main/labs/sections/computing-foundations/day-019-https-and-tls-encryption-on-the
- Get the hands-on files. Clone the labs repository once (you can reuse this clone for every lesson). This works on macOS, Linux, and Windows (PowerShell or WSL):
git clone https://github.com/ai-roadmap-365/ai-roadmap-365.github.io.git cd ai-roadmap-365.github.io - Open this lesson's lab. Move into the directory for this specific day. Every lab lives at the same predictable path — section / subsection / week / day:
cd labs/sections/computing-foundations/day-019-https-and-tls-encryption-on-the - Read the lab guide. Open `README.md` in that directory. It lists the exact commands, what each does, the expected output, and how to check your work — read it before running anything.
- Run it and check your work. Follow the README's "How to run" section: run the example first to see the finished result, then complete the numbered exercises in `starter/`, then run the tests. The tests pass (exit 0) only when your work is correct.
bash tests/run_tests.sh # or the test command named in the lab README
You can also open the lab as a local page (works offline, shows the file tree and expected output).
Learning objectives
By the end of this lesson you will be able to:
- Explain the three protections TLS provides — confidentiality, integrity, and authentication — and why plaintext HTTP is dangerous without them
- Distinguish symmetric from public-key (asymmetric) encryption and explain why TLS combines them: slow public-key setup, fast symmetric bulk encryption
- Trace the TLS handshake step by step, from ClientHello through certificate exchange and key agreement to the encrypted session
- Describe certificates, Certificate Authorities, and the chain of trust, and explain how a browser decides whether to trust a certificate
- State what the padlock does and does not mean, and explain HSTS, certificate expiry, and common certificate errors
- Use openssl s_client and curl -v to inspect a real certificate's subject, issuer, and validity dates and the negotiated TLS version
- Connect HTTPS to online service practice: why API calls travel over HTTPS to protect keys and data, and why deploying a service needs a TLS certificate
Prerequisites
- Day 18 — HTTP: Requests, Responses, and Methods (TLS wraps ordinary HTTP)
- Comfort running commands in a terminal (Days 8–14)
- A computer running macOS, Linux, or Windows with openssl and curl available and a working internet connection
Why this matters
-
Every API key you send travels under TLS, and without it anyone on the path reads it.
-
Certificate errors will stop your deployments, and knowing which of four checks failed turns an hour into a minute.
-
An expired certificate takes a service down completely, and it is the most avoidable outage there is.
-
TLS authenticates as much as it encrypts. Encryption to an impostor is worth nothing, and that is the part people miss.
-
Corporate networks and debugging proxies both work by breaking this, so you need to know what they are doing.
The idea in plain language
-
HTTPS is HTTP inside TLS. The messages are identical; the pipe is protected.
-
TLS does two things: it proves the server is who it claims, and it encrypts everything in both directions.
-
Encryption without identity is useless. A perfectly encrypted channel to an attacker protects the attacker.
-
Two kinds of cryptography are used, because each solves half the problem: slow public-key maths to establish trust, fast symmetric encryption for the data.
-
Trust comes from a chain of signatures ending at an authority your browser already believes.
Historical background
-
The web began entirely in plaintext. Passwords, credit cards, everything.
-
Netscape’s SSL arrived in 1995. Versions 1 and 2 were broken; SSL 3.0 was the first that worked, and is now itself long dead.
-
TLS 1.0 was SSL 3.1, renamed when standardisation moved to the IETF in 1999. People still say “SSL” for what is universally TLS.
-
TLS 1.2, 2008, was the workhorse for a decade.
-
TLS 1.3, 2018, removed everything optional and broken, cut the handshake to one round trip, and made forward secrecy mandatory rather than a choice.
-
Let’s Encrypt, 2015, made certificates free and automatic, and HTTPS went from a minority of the web to the overwhelming default in a few years.
What it is — and what it is not
TLS is:
-
A layer between TCP and HTTP that authenticates one or both sides and encrypts everything above it.
-
A negotiation: the two ends agree on a version and a cipher suite they both support.
-
Independent of HTTP. The same layer protects mail, databases and message queues.
TLS is not:
-
Not a guarantee the site is honest. It proves the server controls that domain, and nothing about whether the domain deserves your trust.
-
Not protection for data at rest. Once the response arrives, TLS is finished.
-
Not hiding everything. The domain you connect to is visible on the wire, even when the path and content are not.
-
Not the same as a padlock meaning “safe”. Phishing sites have valid certificates, because obtaining one only requires controlling the domain.
Why it was created and what problems it solves
-
Eavesdropping. Anyone on the path — a router, a Wi-Fi access point, an ISP — could read every byte.
-
Tampering. Without integrity checking, content could be altered in transit and neither end would know.
-
Impersonation. Without authentication, you cannot tell the real server from one that answered first.
-
Trust at scale. You cannot pre-arrange a secret with every server on earth, which is exactly the problem public-key cryptography solves.
-
A single mechanism for every protocol, so mail, databases and APIs did not each invent their own.
How it works
Two kinds of encryption, and why both
-
Symmetric encryption uses one key to both lock and unlock. Modern TLS commonly uses AES for this.
-
It is fast enough to encrypt gigabytes without noticeable cost, which is why it carries the actual data.
-
Its catch is obvious once said aloud: both sides need the same secret, and handing it across a watched network hands it to the watcher too.
-
Public-key cryptography breaks that deadlock. Each side has a key pair: a public key it publishes and a private key it never shares.
-
The two are mathematically linked so that what one scrambles only the other can unscramble, and a signature made with the private key can be checked by anyone — yet the public key does not reveal the private one.
-
Its cost is speed. Public-key maths is far slower, so TLS uses it only for the brief setup.
The handshake
-
ClientHello. “Here are the TLS versions and cipher suites I support, and some random data.” A cipher suite is a named bundle: key agreement, bulk encryption, integrity.
-
ServerHello and certificate. The server picks a version and suite both support, adds its own random data, and sends its certificate — domain name, public key, expiry date, and the issuing authority’s signature.
-
Verify the certificate. Signed by a trusted authority? Still within its dates? Does the name match the site you asked for?
-
Key agreement. Both sides independently derive the same fresh secret, without it ever crossing the wire usably. Only the holder of the private key can complete this — which ties the encryption to the verified identity.
-
Encrypted session. The slow work is over; every request and response from here uses the fast symmetric key.
-
Public-key cryptography appears once, to authenticate and bootstrap. Symmetric encryption does all the heavy lifting afterwards.
-
That mix is the central engineering idea of TLS.
The chain of trust
-
A Certificate Authority verifies that whoever asks for a certificate for a domain actually controls it, then signs one with its private key.
-
Your browser and operating system ship a trust store: a curated list of a few dozen root authorities trusted by default.
-
Roots are kept offline and precious, so they rarely sign site certificates directly.
-
A root signs intermediates, which are online and do the day-to-day signing of leaf certificates.
-
The browser verifies leaf against intermediate, intermediate against root, and root against its own trusted copy.
-
If any link fails — expired, bad signature, wrong name, unknown root — the whole chain is rejected. There is deliberately no “trust it anyway” default, because a broken chain is exactly what an interception attack looks like.
HSTS: refusing to fall back
-
Type
example.comwithout the scheme and your first request may go out over plain HTTP before being redirected. -
An attacker could hijack that unprotected moment.
-
Strict-Transport-Securitytells the browser: for the next N seconds, only ever use HTTPS for me, and never let the user click through a warning. -
Once seen, every future request is upgraded before it leaves the machine.
-
Major sites are in a preload list shipped inside browsers, so the protection applies even on a first visit.
An everyday analogy
Meeting a stranger who claims to be your bank manager.
| The meeting | TLS |
|---|---|
| ”Prove who you are” | Certificate verification |
| A passport | The certificate |
| The government that issued it | The certificate authority |
| Your belief that the government is real | The trust store |
| Agreeing a private phrase for later | Key agreement |
| The rest of the conversation, in that code | Symmetric encryption |
-
Checking the passport is slow and happens once. The conversation afterwards is fast.
-
A valid passport proves identity, not honesty. A real person with real identification can still be a fraudster — which is precisely why a padlock is not a safety guarantee.
Examples in practice
-
certificate has expired: nothing else is wrong. Someone did not renew, and the whole service is down. -
hostname mismatch: the certificate is valid but issued for a different name. Common when a load balancer is misconfigured. -
unable to get local issuer certificate: the server did not send its intermediate. It works in browsers, which cache intermediates, and fails incurland Python — a genuinely confusing split. -
self signed certificate in certificate chainon a corporate network: traffic is being intercepted and re-signed by a proxy whose root is installed on managed machines. -
A padlock on a phishing site: entirely normal. The certificate proves domain control, not legitimacy.
Implications: security, privacy, performance, scalability, and cost
-
Security: certificate verification is the whole point. Disabling it —
verify=False,-k,rejectUnauthorized: false— turns TLS into encryption to whoever answered. -
A compromised certificate authority compromises everyone it can sign for, which is why Certificate Transparency logs exist: every issued certificate is published, so a domain owner can notice one they did not request.
-
Privacy: the domain is still visible. Historically in the SNI field, and always through DNS. Encrypted Client Hello is the current answer.
-
Performance: TLS 1.3 costs one round trip, and session resumption can cost zero. The old “HTTPS is slow” argument died with TLS 1.2.
-
Cost: certificates are free. Let’s Encrypt removed the last excuse, and automated renewal removed the last common outage.
-
Cost of failure is total. An expired certificate does not degrade a service; it stops it, everywhere, at once.
Alternatives: free, open source, and commercial
| Tool | Type | What it gives you |
|---|---|---|
| Let’s Encrypt + certbot | Free, open source | Automatic issuance and renewal |
| Caddy | Free, open source | A web server that obtains and renews certificates itself |
openssl s_client | Free, built in | The raw handshake and the whole chain |
curl -v | Free, built in | Which check failed, in readable English |
| SSL Labs test | Free | A graded report on a public server’s configuration |
| Commercial CAs | Paid | Organisation validation, warranties, support |
-
Automate renewal or you will forget. Every expired-certificate outage was preventable by a cron job from Day 14.
-
Paid certificates are cryptographically identical to free ones. You are buying validation process and support, not stronger encryption.
Comparison with related concepts
| Term | What it actually is |
|---|---|
| SSL | TLS’s predecessor; the name survives, the protocol does not |
| TLS | The protocol that authenticates and encrypts the connection |
| HTTPS | HTTP carried inside TLS |
| Certificate | A signed statement binding a public key to a domain name |
| CA | The organisation that verifies control and signs |
| Trust store | The root certificates your system believes by default |
| Forward secrecy | Past sessions stay safe even if the private key later leaks |
When to use it — and when not to
-
Use HTTPS for everything, including internal services and local development where you can. There is no longer a cost argument.
-
Use HSTS once you are confident every path is available over HTTPS — it is hard to undo, by design.
-
Verify certificates in every client you write. The default is correct; the override exists for tests.
-
Never disable verification to make an error go away. That error is the system working. Find out which of the four checks failed.
-
Do not treat a padlock as a trust signal for users. It means the connection is private, not that the destination is honest.
-
Do not put a certificate’s private key in a repository. It is a credential, and it is the one that lets someone be you.
The AI connection
-
Every model API call carries your key under TLS. Without verification, a proxy could collect every key you send.
-
SSL: CERTIFICATE_VERIFY_FAILEDin Python is the most common first error on a corporate network, and the fix is installing the company’s root — notverify=False. -
Self-hosted inference servers need certificates too, and “it is only internal” has been the preamble to a great many incidents.
-
Model weights downloaded over an unverified connection could be substituted, and you would have no way to tell.
-
Streaming responses run over a long-lived TLS session, which is exactly the case session resumption was designed for.
Knowledge check
quiz:
question: "A site loads fine in your browser but `curl` reports it cannot get the local issuer certificate. What is the most likely cause?"
options:
- "The server is not sending its intermediate certificate, and the browser has one cached while curl does not"
- "The site's certificate has expired and the browser is ignoring the expiry"
- "The certificate was issued for a different hostname than the one requested"
- "curl does not support the TLS version the server negotiated"
answer_index: 0
explanation: "A server should send its leaf and the intermediate that signed it. Browsers often hold intermediates from previous visits and quietly fill the gap; curl builds the chain only from what it is sent, so an incomplete chain fails there and nowhere else."
Hands-on exercise
Inspect a real certificate, read its chain, and break verification on purpose. Worked through fully in the Day 19 lab directory.
| What you are doing | Command |
|---|---|
| See the whole handshake and chain | openssl s_client -connect example.com:443 -servername example.com |
| Read the certificate’s fields | ... | openssl x509 -noout -text |
| Just the dates | ... | openssl x509 -noout -dates |
| Which check failed | curl -v https://expired.badssl.com |
| Skip verification, and see why not to | curl -k https://self-signed.badssl.com |
| Check a chain is complete | curl -v https://incomplete-chain.badssl.com |
Expected output
depth=2 O = Root CA
depth=1 O = Intermediate CA
depth=0 CN = example.com
notBefore=Jun 1 00:00:00 2026 GMT
notAfter=Aug 30 23:59:59 2026 GMT
curl: (60) SSL certificate problem: certificate has expired
- Three depths are the chain: leaf, intermediate, root.
notAfteris the outage date if nobody renews.
Validate your work
-
You read a real certificate’s subject, issuer and validity dates
-
You identified all three links in a chain
-
You triggered an expiry failure, a name-mismatch failure and a self-signed failure, and can tell them apart from the error text
-
You explained why
-kis unacceptable outside a test -
You found the expiry date of a certificate you depend on
-
bash tests/run_tests.shreports 0 failures
Troubleshooting
-
openssl s_clienthangs. It waits for input after connecting. Press Ctrl+D, or pipe from/dev/null. -
You get the wrong certificate. Without
-servername, no SNI is sent, and a shared host returns its default site. -
Python fails where curl succeeds. They use different trust stores. On macOS, Python ships a script to install certificates.
-
Everything is self-signed on a work laptop. Traffic is being intercepted. Install the company root properly rather than disabling verification.
Common mistakes
- Reaching for
verify=Falseor-kthe moment an error appears. - Renewing manually. It works until the one time you are on holiday.
- Assuming a padlock means the site is trustworthy.
- Committing a private key alongside the certificate it belongs to.
Practice assignment
-
Inspect the certificates of five sites you use and record issuer, expiry and chain length. Note which ones expire soonest.
-
Work through the
badssl.comfailure cases one at a time and write down the exact error each produces in bothcurland Python. -
Set up a local HTTPS server with a self-signed certificate, then add it to your own trust store and watch the error disappear. That is the whole trust model in ten minutes.
-
Write a monitoring script that reports any certificate expiring within thirty days, and schedule it with Day 14’s cron.
Extension challenge
-
Capture a TLS 1.3 handshake with
tcpdumpand identify how little of it is readable compared with a TLS 1.2 capture. -
Search Certificate Transparency logs for a domain you own or control, and see every certificate ever issued for it. Most people find one they did not expect.
-
Measure the handshake cost. Compare a fresh connection with a resumed session, and quantify what resumption saves.
-
Explain forward secrecy to someone else in three sentences, then check yourself: why does an attacker who records traffic today and steals the key next year still learn nothing?
Quiz
Q1. What are the three protections that TLS provides to an HTTP connection?
- Compression, caching, and load balancing
- Speed, redundancy, and anonymity
- Confidentiality, integrity, and authentication
- Encryption, compression, and error correction
Show answer
Answer: C. Confidentiality, integrity, and authentication
TLS provides confidentiality (nobody in the middle can read the data), integrity (nobody can alter it undetected), and authentication (you can be confident the server is genuine). All three are needed together — encryption to an impostor is worthless.
Q2. Why does TLS use public-key cryptography for the handshake but symmetric encryption for the rest of the connection?
- Public-key encryption is illegal for bulk data in most countries
- Symmetric encryption cannot protect data at all, so it is only used as a backup
- Symmetric encryption is more secure than public-key encryption for the handshake
- Public-key math sets up a shared secret; symmetric is fast for bulk
Show answer
Answer: D. Public-key math sets up a shared secret; symmetric is fast for bulk
Public-key cryptography solves the problem of two strangers agreeing on a secret over a watched wire, but it is slow. So TLS uses it briefly to bootstrap a shared symmetric key, then switches to fast symmetric encryption for the actual traffic — the best of both.
Q3. What does a Certificate Authority (CA) actually vouch for when it issues a certificate?
- That the holder controls the domain named in the certificate
- That the website is honest and safe to give your data to
- That the website will never be hacked
- That the website loads quickly and is well designed
Show answer
Answer: A. That the holder controls the domain named in the certificate
A CA verifies that whoever requested the certificate controls the domain, then signs a certificate binding that domain to a public key. It certifies identity (control of the domain), not the honesty, safety, or quality of the site.
Q4. A browser receives a site (leaf) certificate. How does it decide whether to trust it?
- It contacts the website owner by email to confirm
- Leaf against intermediate, intermediate against root, root in the store
- It trusts any certificate that is not expired, regardless of who signed it
- It asks the user to approve every certificate manually
Show answer
Answer: B. Leaf against intermediate, intermediate against root, root in the store
The browser follows the chain of trust upward: each certificate must be validly signed by the one above it, ending at a root CA whose public key is already in the browser or OS trust store. If any link fails, the connection is rejected.
Q5. Which statement about the padlock icon in the address bar is correct?
- It guarantees the website is trustworthy and safe to share data with
- It means the website cannot be hacked
- The connection is encrypted and the domain verified, nothing more
- It appears only on websites owned by large companies
Show answer
Answer: C. The connection is encrypted and the domain verified, nothing more
The padlock confirms the connection is encrypted and the certificate for that domain checked out. It says nothing about whether the site is honest or handles your data well — even a scam site can obtain a valid certificate for its own domain.
Q6. What is the purpose of HSTS (HTTP Strict Transport Security)?
- It compresses HTTPS traffic to make pages load faster
- It lets a site work without any certificate
- It replaces certificates with passwords
- It tells the browser to use HTTPS only, always
Show answer
Answer: D. It tells the browser to use HTTPS only, always
HSTS is a header a site sends telling the browser to use only HTTPS for that site in future and not to allow clicking through certificate warnings, which prevents an attacker from hijacking an initial unprotected HTTP request.
Q7. What is the relationship between SSL and TLS?
- TLS is the modern standard; SSL is its obsolete predecessor
- SSL is the modern, secure version and TLS is obsolete
- They are competing protocols made by different companies today
- They are completely unrelated technologies
Show answer
Answer: A. TLS is the modern standard; SSL is its obsolete predecessor
TLS is the standardized successor to Netscape's SSL. The actual SSL versions are obsolete and insecure, but the name persists in casual usage; when people say "SSL certificate" they almost always mean TLS.
Q8. A service that worked yesterday now shows a certificate error to every visitor, though the code did not change. What is the most likely cause?
- The website's content was rewritten
- The certificate expired and was not renewed
- The visitors all changed browsers at once
- HTTP was upgraded to HTTPS overnight
Show answer
Answer: B. The certificate expired and was not renewed
Certificates are valid only within a not-before / not-after window. A very common outage is a certificate quietly expiring because renewal was not automated, which makes every browser reject the connection until it is renewed.
Glossary
- HTTPS
- HTTP carried inside a TLS-encrypted connection (conventionally on port 443), giving web traffic confidentiality, integrity, and server authentication.
- TLS
- Transport Layer Security, the protocol that wraps a network connection in encryption and authentication; the modern successor to SSL.
- encryption
- Scrambling data with a key so that only someone with the right key can turn it back into readable form.
- symmetric key
- A single shared secret key used to both encrypt and decrypt messages; fast, but both sides must already share the same key.
- public-key cryptography
- Encryption using a matched public/private key pair so two strangers can establish a secret without pre-sharing one; also called asymmetric encryption, and slower than symmetric.
- certificate
- A signed digital document that binds a domain name to a public key and carries an expiry date, presented by a server to prove its identity.
- Certificate Authority
- A trusted organization (CA) that verifies control of a domain and signs certificates for it; browsers ship with a list of trusted CA roots.
- chain of trust
- The sequence of signatures from a site certificate up through one or more intermediate CAs to a root the browser already trusts; if any link fails, the certificate is rejected.
- handshake
- The opening exchange of a TLS connection that authenticates the server and agrees a shared symmetric key, after which data is encrypted symmetrically.
- HSTS
- HTTP Strict Transport Security, a header telling a browser to contact a site only over HTTPS and never allow clicking through its certificate warnings.
- cipher
- An algorithm used to encrypt and decrypt data; TLS negotiates a cipher suite (a bundle of algorithms for key agreement, bulk encryption, and integrity) during the handshake.
- man-in-the-middle attack
- An attack in which someone secretly sits between you and a server, reading or altering traffic while both sides believe the line is private; authentication in TLS is designed to prevent it.
- root CA
- A self-signed Certificate Authority certificate that anchors the chain of trust; its public key is preloaded in the browser or operating system trust store and kept offline for safety.
Sources and further reading
- Transport Layer Security — Wikipedia (accessed 2026-07-12)
- What is HTTPS? — Cloudflare (accessed 2026-07-12)
- How HTTPS works — DNSimple (accessed 2026-07-12)
- High Performance Browser Networking — Transport Layer Security (TLS) — Ilya Grigorik (accessed 2026-07-12)
- Let's Encrypt — How It Works — Let's Encrypt / ISRG (accessed 2026-07-12)
Kept in this browser, no account needed. Your progress page turns the whole record into one link you can bookmark or open on another device.
